7C1Q-6006-FA for FORD TRANSIT V348 2.4L PUMA Duratorq 2.4 Diesel Auto Engine Long Block Du4d24 115Ps 140Ps Engine for Land Rover Defender 2.4 Td4 DT244 Puma 244DT LR013403

7C1Q-6006-FA for FORD TRANSIT V348 2.4L PUMA Duratorq 2.4 Diesel Auto Engine Long Block Du4d24 115Ps 140Ps Engine for Land Rover Defender 2.4 Td4 DT244 Puma 244DT LR013403

Puma 2.4L / JX4D24 Diesel Engine Long Block Assembly Model Compatibility: Compatible with Ford Transit V348, JMC Transit, Land Rover Defender 2.4 Td4. Part Numbers: 7C1Q-6006-FA, DC1Q-6006-AA, 1853818, LR013403, 7H1Q-6006-BA. mainly compatible with Ford Transit V348, JMC Transit V348, and Land Rover Defender models equipped with 2.4L Duratorq Puma diesel engines. Our products cover a full range of part numbers, including 7C1Q-6006-FA, 7C1Q-6006-BA, DC1Q-6006-AA, LR013403, LR055432, and more, perfectly matching engine models such as JX4D24, DU4D24, DU4D244L, DT244, and 244DT with power outputs of 115PS, 140PS, and 122HP.

Overview: The Puma 2.4L / JX4D24 Diesel Engine Long Block is a heavy-duty, high-performance engine assembly designed for commercial vehicles and 4x4 off-roaders. This "Long Block" version includes the engine cylinder block, crankshaft, pistons, connecting rods, and the complete cylinder head assembly. It is engineered to meet the Duratorq 2.4 TDCi High-Pressure Common Rail (HPCR) standards, delivering reliable power outputs of 115PS or 140PS. Whether for vehicle restoration or engine replacement, this assembly ensures factory-level precision and durability.

Model:
DU4D24
Brand:
GL
Code:
7C1Q-6006-FA 7C1Q6006FA 7C1Q-6006-EA 7C1Q-6006EA 7H1Q6006BB 6C1Q-6006-GD 6C1Q-6006-HD 6C1Q6006HD LR013403 LR055432 LR004270 LR006853 LR008028 LR010278 LR016810 LR057902 LR004452 DU4D24 Td4 DT244 17


Availability:



Inquire Add to Basket

Product Description

The DU4D24 is a 2.4L diesel enginefound in vehicles like the JMC Transit and Ford Transit, often associated with the Yuchai 4D24 or a similar variant. It is available as a replacement long block or various other engine components for parts replacement and is sometimes referred to as JX4D24 or by the Ford part number 7C1Q-6006-FA.

Here's a breakdown of key aspects:

Vehicle Applications:

The engine is designed for use in commercial vehicles like the Ford Transit and JMC Transit buses. Land Rover Defender 90 and 110 models.

Main Data and Technical Parameter
Model Number	7C1Q-6006-FA 7C1Q6006FA 7C1Q-6006-EA 7C1Q-6006EA 7H1Q6006BB 6C1Q-6006-GD 6C1Q-6006-HD 6C1Q6006HD LR013403 LR055432 LR004270 LR006853 LR008028 LR010278 LR016810 LR057902 LR004452 DU4D24 Td4 DT244 1749286 1848692 1495922 1853818 H9FB H9FD FXFA JXFA JXF 8C1Q6l084VB 8C1Q6L084AA DU4D244L
Application	Vehicle
Number of Cylinders-Bore*Stroke	4—mm×mm
Fuel supply	electronic injection
Displacement	2.4 Liter
Intake Type	Inter-cool Turbo
Idle Speed	800r/min
Rated output Power/ Rev	90kW/3200r/min
Max. Torque/Speed	3200/1600-2200r/m
Max. Speed	4200r/min
Min. fuel Consumption	205g/kWh
Cold Starting	－20℃
Starting Motor	1 2V/2.8kW
Generator	12V 80A
Oil Capacity	5.6 liter
Exhaust Temperature	≤600℃
Fuel Injection Pump	HPCR
Valve Gap	0.40 ( inlet valve and exhaust valve, cooling)
Inlet Valve Open	24.5℃A before top dead center
Inlet Valve Closing	55.5℃A after bottom dead center
ExhaustValve Open	54℃A before bottom dead center
Exhaust Valve Closing	26℃A after top dead center
Injection Beginning Angle	electronic control
Net Weight	240kg
Size (LWH) mm	707×580×779
